SPECIFICATIONS

Amplification

• Number Of Channels:7
• Stereo RMS Power (watts):120
• THD in Stereo:0.02 %
• Frequency Bandwidth (stereo):20-20k Hz
• Minimum Impedance L/R:8 ohms
• Minimum Impedance Center:8 ohms
• Minimum Impedance Surround:8 ohms

General Features

• Bluetooth:Built-in
• Apple AirPlay:AirPlay 2
• Alexa-compatible:No
• Google Assistant-compatible:Yes
• Chromecast built-in:Yes
• DTS Play-Fi:No
• App Remote Control:Yes
• On-Screen Display:Thru HDMI
• Auto Speaker Calibration:Dirac Live

Multi-room Audio/Video

• Powered Multi-room Audio Output:Yes
• Preamp Multi-room Audio Output:Yes
• Multi-room HDMI Output:Yes
• Total Number of Zones:2
• Playback from Digital Audio Inputs:No
• Playback from Streaming Sources:Yes

Surround Processing

• Dolby Digital:DD, TrueHD, DD+
• Dolby Atmos:Yes
• Dolby Atmos Height Virtualization:Yes
• DTS:DTS, HD, HDMA, ES, 96/24
• DTS:X:Yes
• DTS Virtual:X:Yes

Inputs & Outputs

• Phono Input:No
• Audio-Video Inputs:7
• Audio-only Inputs:2
• Component Video Inputs:None
• Component Video Monitor Outputs:None
• Optical Digital Inputs:2
• Coaxial Digital Inputs:4
• Optical Digital Outputs:1
• Coaxial Digital Outputs:None
• Number of HDMI Inputs:7
• HDMI Monitor Outputs:2
• Subwoofer Outputs:2
• Discrete Subwoofer Outputs:Yes
• Multi-Channel Analog Input:No
• Multi-channel Preamp Output:Yes
• Main Speaker Output Pairs:Posts
• Main Speaker Terminals:Posts
• Ethernet Port:Yes
• USB Connections:Service only
• Removable Power Cord:IEC 2-prong
• Supports Wireless Rear Speakers:No

HDMI Features

• HDMI Version:2.1
• VRR (Variable Refresh Rate):No
• ALLM (Auto Low Latency Mode):No
• 4K/120Hz-Capable Inputs:7
• Audio Return Channel:eARC supported
• Video Upscaling:No

HDR (High Dynamic Range) Support

• HDR10:Yes
• HDR10+:Yes
• HLG:Yes
• Dolby Vision:Yes

Other Specs

• DAC Bit Depth:24-bit
• DAC Sample Rate:192 kHz
• FM Sensitivity:Not Given
• Multibrand Remote Control:Yes
• Learning Remote:Yes
• Width (inches):17.0625
• Height (inches):6.6875
• Depth (inches):18.5625
• Weight (pounds):39.9
