| 2 channels driven, 1kHz, 4Ω | 200W |
| Harmonic distortion, 80% power, 8Ω at 1kHz | 0.002% |
| Number of inputs | 3 (RCA pairs) |
| Phono Inputs | MM and MC |
| Frequency response | 20Hz.20kHz ± 0.2dB |
| Supported Streaming media | FLAC, WAV (LPCM), AAC, ALAC, AIFF, DSD (up to 256), MP3, MP4, OGG, WMA |
| Supported Streaming Bit depth | 16, 24, 32 |
| Supported Streaming sample rates (kHz) | Up to 384 kHz |
| Gapless Playback | Yes |
| Digital Audio Inputs | 1x HDMI eARC, 2x Coaxial (RCA), 2x Optical (Toslink) |
| Supported Digital input Bit depth | 16, 24 |
| Supported Digital input sample rates (kHz) | Up to 192 kHz |
| Frequency response (filter 1) | 20Hz.20kHz ± 0.2dB |
| Bluetooth Transmitter Frequency and Power | 2,400 MHz to 2,483.5 MHz: <20dBm |
| Wi-Fi Network | IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz) |
| Mains voltage | 100V or 110–120V or 220–240V, 50–60Hz |
| Power consumption (maximum) | 700W |
| Power consumption (standby) | <0.5W |
| Weight (net) | 12 kg |
| Weight (packed) | 14 kg |
SPECIFICATIONS
Services
Works with (apps):
ARCAM Radia
Spotify (Connect)
Tidal (Connect)
Qobuz (Connect)
Roon Ready (coming soon)
Works with (services):
Apple Airplay
Google Cast
ARCAM Radia supported services (Global):
Internet Radio
Podcasts
UPnP
USB Media (using USB-A mass storage input)
Continuous power output (0.5% THD), per channel
2 channels driven, 20Hz . 20kHz, 8Ω: 120W
2 channels driven, 1kHz, 4Ω: 200W
Harmonic distortion, 80% power, 8Ω at 1kHz: 0.002%
Analogue Inputs
Number of inputs: 3 (RCA pairs)
Phono Inputs: MM and MC
Frequency response: 20Hz.20kHz ± 0.2dB
Signal/noise ratio (A-wtd, ref. 50W, 1V input): 106dB
Digital Inputs
Supported Streaming media: FLAC, WAV (LPCM), AAC, ALAC, AIFF, DSD (up to 256), MP3, MP4, OGG, WMA
Supported Streaming Bit depth: 16, 24, 32
Supported Streaming sample rates (kHz): Up to 384 kHz
Gapless Playback: Yes
Digital Audio Inputs: 1x HDMI eARC, 2x Coaxial (RCA), 2x Optical (Toslink)
Supported Digital input Bit depth: 16, 24
Supported Digital input sample rates (kHz): Up to 192 kHz
Frequency response (filter 1): 20Hz.20kHz ± 0.2dB
Signal/noise ratio (A-wtd, ref. 50W, 0dBFS): 110dB
Wireless Specifications
Bluetooth Profile 5.4; A2DP Sink/Source, AVRCP, BLE, Snapdragon Sound, AAC, LE Audio, Auracast
Bluetooth Transmitter Frequency and Power: 2,400 MHz to 2,483.5 MHz: <20dBm
Wi-Fi Network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi Transmitter Frequency Range and Power:
2400-2483.5 MHz (USA 11 Channels, Europe and Others 13 Channels): <20dBm
5G Wi-Fi Transmitter Frequency Range and Power:
5150-5250 MHz <23dBm
5250-5350 MHz <20dBm
5470-5725 MHz <20dBm (Not used in China)
5725-5850 MHz <14dBm for EU, <33dBm for other regions.
General
Mains voltage: 100V or 110–120V or 220–240V, 50–60Hz
Power consumption (maximum): 700W
Power consumption (standby): <0.5W
Dimensions W x D (including speaker terminals) x H (including feet):
432 x 344 x 99mm
Weight (net): 12 kg
Weight (packed): 14 kg
Supplied accessories:
Mains lead(s)
Remote control with 2 x AAA batteries
Measurement Microphone
5m USB Cable
Quick Start Guide
